Chapter 4 Electra 9200 Specifications General Features
© 2015 Harmonic Inc. All rights reserved. 27 Electra 9200, Rev O
Transport
Outputs
n MPEG-2 Transport Stream over UDP/IP (redundant 10/100/1000 BaseT
connectors)
IP output
n Two 10/100/1000 Base-T por ts
n Dual-mode IP output or manual channel switch for redundancy
n Same-source IP output support
n Automatic port redundancy
n UDP and HRTP encapsulation support
n Unicast and multicast address support
n Ping and ARP support
n Single and multiple program transport stream (SPTS and MPTS) output
n Null packets can be preserved to match the exact rate of SPTS (video server
integration)
n Forward-error correction (FEC) may be applied via the SMPTE 2022 Annex C
method. Use of FEC requires RTP encapsulation.
n Connector type: RJ-45
n Harmonic Heartbeat Protocol (HHP) redundancy protection
IP input
b
n Two 10/100/1000 Base-T por t
n Dual-mode IP output or manual channel switch for redundancy
n Same-source IP output support
n Automatic port redundancy
n UDP and RTP encapsulation support
n Unicast and multicast address support
n Ping and ARP support
n Connector type: RJ45
PSI support n Generated by NMX when managed by NMX
Alarms n Current and history alarm logs in NMX Alarm Manager
n SNMP alarm forwarding
IRIS™ Suppor t n Quality of Service (QoS) Data reporting for video and audio quality. This data can
by used for performance analysis by Harmonic’s IRIS system or by a third-party
system.
a. The surround mix on the three AES3 pairs uses channel mapping per SMPTE 320M (L/R, C/Lfe, Ls/Rs).
b. Feature available with optional firmware licence.
Table 4-1: General Features continued
Feature Description
