Chapter 9 ATSC RF Input Module RF Module LED Lights
© 2015 Harmonic Inc. All rights reserved. 74 Electra 9200, Rev O
RF Module LED Lights
The LED lights show status, as shown in Table 9–2.
Table 9–2: LED Status Lights
Display Status
Off Port disabled
Blinking Yellow Loss of sync
Red Packet error rate (PER) threshold exceeded
Steady yellow SN R below threshold
Green Port Enabled, no alarms
