Chapter 4 Electra 9200 Specifications Video Features
© 2015 Harmonic Inc. All rights reserved. 29 Electra 9200, Rev O
Video Features
The encoder is equipped to handle serial digital video..
Table 4–3: Video Features
Feature Specification
Input formats Serial digital component, SD (SMPTE 259M) or HD (SMPTE
292)
Video Compression and bit
rate (CBR/VBR) 4:2:0
encoding options
Broadcast profiles:
n MPEG-2 MP@ML 1 to 15 Mbps
n MPEG-2 MP@HL 2 to 24 Mbps
n MPEG-2 MP@HL 24 Mbps to 45 Mbps (Option: 29.97
Hz)
n MPEG-4 AVC MP@L3 0.3 to 8 Mbps
n MPEG-4 AVC HP@L4 1 to 20 Mbps
Video Processing n LookAhead multi-pass processing
n Scene-cut and fade/dissolves detection
n Dynamic GOP management with adaptive I picture and B
picture placement
n Automatic input format (1080PsF23.97, 1080i or 720p)
detection and switching
Video Input Filtering n Motion compensated temporal filter (MCTF)
n Horizontal filter
n Mosquito noise reduction
n Input deblocking
n Sharpening
Aspect Ratios n 4:3 and 16:9
n AFD and WSS control
SD Resolutions and frame
rates
576i@25, 480i@29.97 × 720, 704, 640, 544, 528,480,
352 pixels
HD Resolutions and frame
rates
720P @50 and 59.94, × 1280 and 960 pixels
1080i @25 and 29.97, 1080PsF24, ×1920, 1440, 1280
and 960 pixels
Ancillary Resolution Option
(PIP)
96 × 96, 128 × 96, 192 × 192 (AVC MP@L1.3)
Up/Down/Cross
conversions
n Conversion between 480i29.97, 720p59.94, and
1080i29.97
n Conversion between 576i25, 720p50, and 1080i25
n Conversion between 720p59.94 and 1080i29.97 or
1080i29.97 and 720p59.94
Digital Program Insertion SCTE 35 insertion via SCTE 104 or VANC DPI triggers
