Chapter 7 FLEX Decoding Module Output Specifications
© 2015 Harmonic Inc. All rights reserved. 70 Electra 9200, Rev O
Output Specifications
Table 7–12 describes the output specifications supported by the FLEX-1 module.
Environmental and Physical
Compliant with ROHS Directive 2002/95/EC. For additional information, Environment
Specifications
Installing the FLEX-1 Decoding Module
This section describes how to install the FLEX Decoding Module. The module’s ports are
shown in Figure 7–1.
Host encoders are typic ally ordered from the factory with the FLEX-1 Module already
inst alled.
ESD Safety Precautions
To protect modules from electrostatic discharge (ESD), follow these s afety precautions:
n Always wear a properly grounded antistatic wrist strap whenever handling the modules.
n Keep the module inside the antistatic bag until you are ready to install the module in a
chassis.
Installing a Module
Refer to Removing and Replacing an Input/Output(I/O) Module for instructions on how to install a
module.
Table 7–12: Outputs Specifications
Feature Support
Video Outputs
n One (1) per decoded channel with video only, via
internal midplane
n One (1) per channel for confidence monitoring only
Connector Type n DIN 1.0/2.3 (DIN 1.0/2.3 to BNC modules available)
Embedded Data along the
Video
n No Audio, VBI, VANC or HANC data embedded in the
SD/HD monitoring outputs. This data is passed via the
internal mid-plane connection.
