Appendix A Encoder Physical Specifications Environment Specifications
© 2015 Harmonic Inc. All rights reserved. 75 Electra 9200, Rev O
Appendix A
Encoder Physical Specifications
This appendix contains a comprehensive list of the environment specifications, electrical
specifications, and physical characteristics of the encoder.
Environment Specifications
Table A–1 lists environment specifications for the encoder.
Table A–1: Environment Specifications
Parameter Specification
Size (WxHxD) 48.26 cm x 4.31 cm x 69.07 cm
(19 in x 1.7 in x 27.2 in (1RU))
Weight 14.5 kg (32 lb.)
AC Power
Input voltage range AC 100 – 240V (auto ranging)
Line frequency 47 to 63 Hz
Typical consumption 109 W for ELC-9200 (1 channel)
150 W for ELC-9200 (2 channels)
191 W for ELC-9200 (3 channels)
232 W for ELC-9200 (4 channels)
153 W for ELC-9200 (1 channel with FLEX/GbE)
194 W for ELC-9200 (2 channels with FLEX/GbE)
253 W for ELC-9200 (3 channels with FLEX/GbE)
294 W for ELC-9200 (4 channels with FLEX/GbE)
4 W per AHC-561 module
2.8 W per AHC-RAC module
6.5 W per ASI module
Fuse (available only on
Electra 9200 single power
supply model)
6.3A,250V,fuse5x20mm
DC Power
Nominal input –48 VDC
Input voltage range –40 to –60 VDC
Temperature
Operating +32º to +122º F
0º to +50º C°
Storage –20 to +80 °C (–4 to +176 °F)
