Table A–2 lists the specifications for the back panel port connections. For port locations, see
the illustration of the back panel on Figure 1–2.
Humidity
Operating < 95% noncondensing
Storage < 95% noncondensing
Altitude
Operating < 15,000 feet (4,572 meters)
Storage < 40,000 feet (12,192 meters)
Shock and Vibration
Packaged Passes the impact, compression, and vibration
requirements of ASTM D4169-94, Distribution Cycle 13,
Assurance Level 1
Operating Passes NEBS Office Vibration Test while operating
(0.1G sine sweep, 5 to 100 Hz, 3 axis)
RoHs Compliance The Electra 9200 is compliant with RoHS Directive 2002/
95/EC
Table A–2: Port Specifications
Port Connection Specification
Video input port
Protocol Serial Digital:
n Standard Definition signal format per SMPTE 259M
n Data stream format per ITUR BT 601
n High Definition signal format per SMPTE 292M
Impedance 75 unbalanced
Connector type BNC
Digital audio input
Input Up to three stereo pairs or one multi channel for the on-
board audio
Format Embedded in SDI
AES3 signal format per AES3-2003 and ITU-R BS.647-2
S/PDIF signal format per IEC 60958
