Appendix A Encoder Physical Specifications RJ-45 Ethernet Port Pinouts
© 2015 Harmonic Inc. All rights reserved. 77 Electra 9200, Rev O
RJ-45 Ethernet Port Pinouts
Table A–3 lists the pinouts for the RJ-45 Ethernet port.
Ethernet management port
Type 10/100/1000 Mbps
Protocol 802.3
Connector type RJ-45
Input serial port SMPTE 333 Service
Ethernet output port
Type 10/100/1000 Mbps
Protocol MPEG-2/ MPEG-4 over IP
Connector type RJ-45
Ethernet input ports
Type 10/100/1000 Mbps
Protocol MPEG-2/ MPEG-4 over IP
Connector type RJ-45
Fault relay port Capable of switching 0.25 amps at 30 VDC
Mating connector type Phoenix 1881383
Table A–3: RJ-45 Ethernet Port Pinouts
Pin Signal
1 Transmit data (TD) +
2 Transmit data (TD) –
3 Receive data (RD) +
4 Not connected
5 Not connected
6 Receive data (RD) –
7 Not connected
8 Not connected
Table A–2: Port Specifications continued
Port Connection Specification
