Constellation® January 2006
2-18 Frequency Planning
Table 2-20:FCC Form 601continued
Product Name Freq
Tolerance
%
Max
Output
Pwr
a
(Not
required
on Form
601)
a. Maximum Output Power (FCC Form 415 - Obsolete 2001) was replaced by Effective Isotropic Radiated Power (EIRP)
radiated off the transmitting antennat (FCC Form 601).
EIRP
b
b. The EIRP value is objtained from the Frequency Coordination data or Link Calculations.
Emission
Designator
Basebad
Digital
Rate
(kbps)
Digital
Modulation
Type
Tx
Manufacturer
Equipment ID ATPC
(Y/N)
c
Item 6 Item 7 Item 8 Item 9 Item 10 Item 11 Item 12 Item 13
Constellation
10 GHz
8DS1 0.0003 - - 3M75D7W 13,800 32 QAM Harris Corp. HRS-CX-10G08D1 -
16DS1 0.0003 - - 5M0D7W 27,100 128 QAM Harris Corp. HRS-CX-10G16D1 -
16DS1 High Gain 0.0003 - - 5M0D7W 28,614 128 TCM Harris Corp. HRS-CX-10G16D1-H -
Constellation 11 GHz
8DS1 0.0003 - - 3M75D7W 13,800 32 QAM Harris Corp. HRS-CX-11G08D1
16DS1 0.0003 - - 5M0D7W 27,100 128 QAM Harris Corp. HRS-CX-11G16D1
28DS1 0.0003 - - 10M0D7W 47,000 64 QAM Harris Corp. HRS-CX-11G28D1
155M 0.0003 - - 30M0D7W 172,560 128 TCM Harris Corp. HRS-CX-11G155M
4DS3 0.0003 - - 30M0D7W 197,419 256 TCM Harris Corp. HRS-CX-11G4DS3
16DS1 High Gain 0.0003 - - 5M0D7W 28,614 128 TCM Harris Corp. HRS-CX-11G16D1-H
28 DS1 High Gain 0.0003 - - 10M0D7W 50,282 64 TCM Harris Corp. HRS-CX-11G28D1-H
155 M High Gain 0.0003 - - 30M0D7W 172,560 128 TCM Harris Corp. HRS-CX-11G155M-H
4DS3 High Gain 0.0003 - - 30M0D7W 197,419 256 TCM Harris Corp. HRS-CX-11G4DS3-H
c. Constellation Transmitters are equipped with a software controlled ATPC feature. If ATPC is required for the path enter Yes
(ATPC enabled). If not required, enter No (ATPC disabled).
