Harris Corporation Constellation®
System Interconnection 5-7
SYSTEM
INTERCONNECT
AND
CONFIGURATION
SCAN Equipment Interconnection
Table 5-7 describes the interconnection between Harris MCD SCAN (system
control and alarm network) equipment and the Constellation radio.
Table 5-7: SCAN equipment interconnection
Constellation
Port
Connector
Type
Radio
Equipment
Port Connector
Type
Signal
AUX RJ45 Constellation AUX RJ45 RS-422
SPUR SPUR
VERSAT1LITY RJ45 CAU COMM 1 DE-9 female RS-232
or
RS-423*
COMM 2
COMM 3
RTU
DVA COMM 1 DE-9 female RS-232
or
RS-423*
COMM 2 RS-232
or
RS-423*
COMM 3 RS-423*
COMM 4 RS-423*
COMM 5 RS-423*
DVM/DVL/ INT CTL DB-25 female RS-423*
DVT EXT B
GlobeStar RTU DE-9 female RS-232
or
RS-423*
MegaStar AUX DE-9 female RS-232
or
RS-423*
SPUR
MicroStar
L/M/H
RTU DE-9 female RS-232
or
RS-423*
