ACU Port Configurations 6-9
ANTENNA
COUPLING UNIT
(ACU)
ACU Port Configurations
Table 6-5: ACU port configurations
Available ACU Configuration Port 1 Port 2 Port 3
NP (Tx/Rx) TX/RX
NP SD (Tx/Rx, Rx) TX/RX RX
HS (Tx/Rx) TX/RX
HS SD (Tx/Rx, Rx) TX/RX RX
HS, 2 antennas (Tx/Tx, Rx/Rx) TX/TX RX/RX
HS/FD, 2 antennas (Tx/Rx, Tx/Rx) TX/RX TX/RX
FD, 1 antenna (Tx/Tx/Rx/Rx) TX/TX/RX/RX
FD, 2 antennas (Tx/Tx, Rx/Rx) TX/TX RX/RX
NP, 2 antennas (Tx, Rx) TX RX
HS SD, 3 antennas (Tx, Rx, Rx) TX RX RX
NP SD, 3 antennas (Tx, Rx, Rx) TX RX RX
