6-8 Antenna Coupling Unit (ACU)

Figure 6-9: ACU, repeater/dual terminal, mechanical

drawing

Table 6-4: X dimension from floor, ACU, repeater/dual

terminal

ACU frequency (GHz) X dimension (inches)

680.24

7/8 79.61

11 79.25

See

Tabl e 6-4

See

Tabl e 6-5
