Harris Constellation - Figure 3-3: Multiplexer Configuration for a Radio-To-Radio Repeater; Figure 3-4: Multiplexer Configuration for a Dual Radio Terminal

Constellation® January 2006
3-6 Constellation Radio Configurations
Figure 3-3: Multiplexer configuration for a radio-to-radio
repeater
Figure 3-4: Multiplexer configuration for a dual radio
terminal
RADIO
A
MODEM
A
MUX
JF
1-16 DS1s
(in group of 4 DS1s
RADIO
B
MODEM
B
JF
1-16 DS1s
8 to 28 DS1s
SERVICE
CHANNEL
(EXPANSION SHELF)
(in group of 4 DS1s
to any M12 slot 1-4) to any M12 slot 5-8)
RADIO
A
MODEM
A
MUX
JF
RADIO
A
MODEM
A
JF
1-28 DS1s
MUX
SERVICE
CHANNEL
SERVICE
CHANNEL
(in group of 4 DS1s)
(in group of 4 DS1s)
1-28 DS1s
