Harris Corporation Constellation®
TECHNICAL
SPECIFICATIONS
C HAPTER
4
TECHNICAL SPECIFICATIONS
Power Requirements (Top of Rack)
Power Consumption
*Notes
1. Measured values.
2. 8/16/28 DS1 repeater power consumption = 2 x terminal consumption, less 5%.
3. Add 3.5 W for each M12 Unit.
4. DS3, 3DS3, 4DS3 and 155 Optical/Electrical use back-to-back terminals.
5. For high system gain options, add 4W per transmitter.
Power Consumption* (watts)
6, 7/8 GHz 10/11 GHz
Configuration, Terminal 24 V 48 V 24 V 48 V
Nonprotected 205 180 225 215
Nonprotected/space diversity Rx 315 270 360 335
Fully protected 405 360 450 425
