Harris Constellation - Regulatory Information Licensed Part 101 Service

Harris Corporation Constellation®
Regulatory Information Licensed Part 101 Service 2-17
FREQUENCY
PLANNING
Regulatory Information Licensed Part 101
Service
Table 2-20:FCC Form 601
Product Name Freq
Tolerance %
Max Output Pwr
a
(Not required on Form 601)
a. Maximum Output Power (FCC Form 415 - Obsolete 2001) was replaced by Effective Isotropic Radiated Power (EIRP)
radiated off the transmitting antennat (FCC Form 601).
EIRP
b
b. The EIRP value is objtained from the Frequency Coordination data or Link Calculations.
Emission Designator
Basebad Digital Rate (kbps)
Digital Modulation Type
Tx Manufacturer
Equipment ID ATPC
(Y/N)
c
c. Constellation Transmitters are equipped with a software controlled ATPC feature. If ATPC is required for the path enter
Yes (ATPC enabled). If not required, enter No (ATPC disabled).
Item 6 Item 7 Item 8 Item 9 Item 10 Item 11 Item 12 Item 13
Constellation 6 GHz
8DS1 0.0003 - - 3M75D7W 13,800 32 QAM Harris Corp. HRS-CX-06G08D1 - 16DS1 0.0003 - - 5M0D7W 27,100 128 QAM Harris Corp. HRS-CX-06G16D1 - 28DS1 0.0003 - - 10M0D7W 47,000 64 QAM Harris Corp. HRS-CX-06G28D1 - 155M 0.0003 - - 30M0D7W 172,560 128 TCM Harris Corp. HRS-CX-06G155M - 4DS3 0.0003 - - 30M0D7W 197,419 256 TCM Harris Corp. HRS-CX-06G4DS3 - 16DS1 High Gain 0.0003 - - 5M0D7W 28,614 128 TCM Harris Corp. HRS-CX-06G16D1-H - 28 DS1 High Gain 0.0003 - - 10M0D7W 50,282 64 TCM Harris Corp. HRS-CX-06G28D1-H - 155 M High Gain 0.0003 - - 30M0D7W 172,560 128 TCM Harris Corp. HRS-CX-06G155M-H - 4DS3 High Gain 0.0003 - - 30M0D7W 197,419 256 TCM Harris Corp. HRS-CX-06G4DS3-H -
Constellation 7/8 GHz
8DS1 0.0003 - - 3M75D7W 13,800 32 QAM Harris Corp. HRS-CX-07G08D1 - 16DS1 0.0003 - - 5M0D7W 27,100 128 QAM Harris Corp. HRS-CX-07G16D1 - 28DS1 0.0003 - - 10M0D7W 47,000 64 QAM Harris Corp. HRS-CX-07G28D1 - 155M 0.0003 - - 30M0D7W 172,560 128 TCM Harris Corp. HRS-CX-07G155M - 4DS3 0.0003 - - 30M0D7W 197,419 256 TCM Harris Corp. HRS-CX-07G4DS3 - 16DS1 High Gain 0.0003 - - 5M0D7W 28,614 128 TCM Harris Corp. HRS-CX-07G16D1-H - 28 DS1 High Gain 0.0003 - - 10M0D7W 50,282 64 TCM Harris Corp. HRS-CX-07G28D1-H - 155 M High Gain 0.0003 - - 30M0D7W 172,560 128 TCM Harris Corp. HRS-CX-07G155M-H - 4DS3 High Gain 0.0003 - - 30M0D7W 197,419 256 TCM Harris Corp. HRS-CX-07G4DS3-H -
