Constellation® January 2006
4-20 Technical Specifications
Mechanical Dimensions
EIA Rack
Refer to Appendix A for information on a Harris standard rack.
Constellation Radio
* Radio mounts in a standard 19-inch wide rack. Dimensions include branching
circulators, fully configured ACU and doors. Cannot be flush-mounted.
** With ADM. 1-3xDS3 and OC3 use back-to-back terminals.
Weights (Typical)
Configuration* Unit Height Depth Width
Terminal Millimeters 622 300 445
Inches 24.5 11.8 17.5
8/16/28xDS1
Repeater**
Millimeters 1200 300 445
Inches 47.25 11.8 17.5
Configuration pound kg
Constellation terminal (fully equipped)
(MHSB, 28 x DS1 terminal)
74 33.6
Constellation repeater (fully equipped) 127 57.6
7-foot x 19-inch rack 35 15.9
