5-8 System Interconnect and Configuration
* RS-423 is with inverted Mark/Space polarity.
Refer to the Constellation Installation and Maintenance
Manual for detailed pinout information.
Monitor RJ45 CAU COMM 1 DE-9 female RS-232
COMM 2
COMM 3
RTU
DVA COMM 1 DE-9 female RS-232
COMM 2
GlobeStar RTU DE-9 female RS-232
MegaStar AUX DE-9 female RS-232
SPUR
MicroStar
L/M/H
RTU DE-9 female RS-232
FSCAN RJ45 FarScan PC COMM DE-9 male RS-232
HNM UNIX
Station
COMM DB-25 female RS-232
ETHERNET RJ45 StarView PC LAN RJ45 10Base-T
Table 5-7: SCAN equipment interconnection (Continued)
Constellation
Port
Connector
Type
Radio
Equipment
Port Connector
Type
Signal
To Next Page
