Harris Corporation Constellation®
RF Performance Specifications 4-9
TECHNICAL
SPECIFICATIONS
10.5 to
10.6;
11.1 to
11.6
OC-3/3xDS3
Standard Gain
NP 25.0 -71.5 -70.0 96.5 95.0
NP/SD 25.0 -71.5 -70.0 96.5 95.0
HS
d
24.6 -70.5 -69.0 95.1 93.6
HS/SD 24.6 -71.5 -70.0 96.1 94.6
ST/SD 24.6 -71.5 -70.0 96.1 94.6
FD 25.0 -71.5 -70.0 96.5 95.0
FD/SD 25.0 -71.5 -70.0 96.5 95.0
OC-3/3xDS3
High Gain
NP 28.5 -71.5 -70.0 100.0 98.5
NP/SD 28.5 -71.5 -70.0 100.0 98.5
HS
d
28.1 -70.5 -69.0 98.6 97.1
HS/SD 28.1 -71.5 -70.0 99.6 98.1
ST/SD 28.1 -71.5 -70.0 99.6 98.1
FD 28.5 -71.5 -70.0 100.0 98.5
FD/SD 28.5 -71.5 -70.0 100.0 98.5
4xDS3
Standard Gain
NP 25.0 -68.0 -67.0 93.0 92.0
NP/SD 25.0 -68.0 -67.0 93.0 92.0
HS
d
24.6 -67.0 -66.0 91.6 90.6
HS/SD 24.6 -68.0 -67.0 92.6 91.6
ST/SD 24.6 -68.0 -67.0 92.6 91.6
FD 25.0 -68.0 -67.0 93.0 92.0
FD/SD 25.0 -68.0 -67.0 93.0 92.0
4xDS3
High Gain
NP 28.5 -68.0 -67.0 96.5 95.5
NP/SD 28.5 -68.0 -67.0 96.5 95.5
HS
d
28.1 -67.0 -66.0 95.1 94.1
HS/SD 28.1 -68.0 -67.0 96.1 95.1
ST/SD 28.1 -68.0 -67.0 96.1 95.1
FD 28.5 -68.0 -67.0 96.5 95.5
FD/SD 28.5 -68.0 -67.0 96.5 95.5
a. System gain = Tx power output - receive threshold.
b. Configurations:
NP = nonprotected transmitter and receiver
NP/SD = nonprotected transmitter, space diversity receivers
HS = hot standby transmitters, protected receivers
HS/SD = hot standby transmitters, space diversity receivers
ST/SD = split transmitters/space diversity receivers; separate main (transmit and receive) and space
diversity (transmit and receive) antennas.
FD = Frequency diversity transmitters and receivers.
FD/SD = Frequency diversity transmitters, space diversity receivers or hybrid diversity receivers.
c. System gain is 1 dB lower for LL6 GHz band (5860-5915 MHz).
d. For HS, thresholds are for RCVR 1 (main); thresholds for RCVR 2 (standby) are approximately 6 dB
higher.
Table 4-3: RF performance specifications (Continued)
Receive
Threshold
System Gain
a
Band (GHz) Capacity Config-
uration
b
Tx Pwr
Output
(dBm)
10
-3
BER
(dBm)
10
-6
BER
(dBm)
10
-3
BER
(dB)
10
-6
BER
(dB)
