Harris Corporation Constellation®
System Interconnection 5-3
SYSTEM
INTERCONNECT
AND
CONFIGURATION
Refer to the Constellation Installation and Maintenance
manual for detailed pinout information.
DATA PORT RJ45 DVSII DATA1 50-pin
female
RS-232
1 & 2 DATA2
DATA3
DATA4
MegaStar DATA1 DA-15
female
DATA2
MicroStar
L/M/H
DATA DE-9 female
Table 5-1: Orderwire interconnection (Continued)
Constellation
Port
Connector
Type
Radio
Equipment
Port Connector
Type
Signal
