1-12 888-2587-001 4/18/11
WARNING: Disconnect primary power prior to servicing.
FM HD Radio System
Section 1 Introduction/Specifications
grounding systems and technique must be used in and around the facility, and lightning
protection must be in place for any type of signal entering or leaving the facility.
1.6.1 ZHD+ Transmitter Features
• Linearized Power Amplifier to meet the FCC NRSC-5 mask, or can be re-biased on-
the-fly for Class C FM operation.
• Redundant, autoswitching, IPA amplifiers to eliminate a single point of failure.
• Microprocessor based controller for advanced control, diagnostics and display capa-
bility. Includes built-in logic and commands for switching parameters for all 4 modu-
lation formats, and can monitor and switch RF sources and IPAs upon a malfunction.
• Redundant RF amplifier modules that allow maintenance while the transmitter
remains on the air at reduced power (“Hot-Pluggable” modules).
• Redundant power supplies to keep the transmitter on the air.
• Broadband design to eliminate tuning adjustments from 87 through 108MHz.
• High performance air cooling design using an internal blower.
• Independent power settings based on 4 four modulation formats, including corre-
sponding alternate power settings for use with a UPS or generator backup system.
• Directional RF sample port provided for customer use.
• Available for single or three phase mains power (3 or 4 wire), 50/60Hz. operation.
1.7 HTX Transmitter
1.8 ZX Transmitter
The ZX transmitter family incorporates many of the same features as the Z-HD+
transmitter in a compact low-power platform suitable for mounting in a standard EIA
19" rack. For more information, please consult the ZX Transmitter Instruction Book
(part number 888-2594-001).
