WARNING: Disconnect primary power prior to servicing.
FM HD Radio System
Section 2 Installation & Initial Turn-On
2.3 System Site Considerations
ALL CONNECTIONS REFERRED TO IN THIS INSTALLATION PROCEDURE
SHOULD BE VERIFIED USING THE SCHEMATICS SUPPLIED WITH THE
TRANSMITTER. THE SCHEMATICS SHOULD BE CONSIDERED THE MOST
ACCURATE IN CASE OF A DISCREPANCY.
To facilitate proper installation and initial checkout, all applicable technical
documentation should be carefully studied to obtain a thorough understanding of the
principles of operation, circuitry, nomenclature, and performance characteristics for
each piece of system equipment to be installed.
The transmitter installation is accomplished in the following order:
1. Equipment Placement
2. HDx-FM Exciter/Boost Pro Installation
3. Air System and Cooling
4. Grounding
5. Power Supply Connections
6. Audio Connections
7. Data Connections
8. Initial Turn On
9. Remote I/O Wiring
2.3.1 Equipment Placement
State, County, and Local Electrical Code may require more distance, but a mini-
mum clearance of 36 inches is recommended for front and rear access to system
equipment.
If the system equipment is to be positioned into a predetermined wall opening, be sure
to allow for any final leveling needed when figuring the wall opening dimensions.
