Chapter 1: Introduction
HMX6801+C4
Figure 1-5 shows the double-slot back connector used by the
HMX6801+C4 module when installed in an FR6802+XF frame.
Figure 1-5. HMX6801+C4 Back Connector
SDI IN
DATA I/O
1
2
SDI
OUT
AUX IN
AES
IN
3
4
2
1
3
Reserved for
future use
Unbalanced AES
input channels
SDI video
outputs
SDI video input
Reserved for
future use
