HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual 35

Chapter 3: Operation

Parameter Availability based on Operating

Mode

Depending on whether the operating mode is HD or SD, some

parameters will be enabled and some disabled. The HD parameters will

apply when SdiStdSet is set to one of the HD operating modes, or when

the SdiStdSet is set to Auto and SdiStdFdbk is one of the HD operating

modes. The SD parameters will apply when SdiStdSet is set to either

SD 525 or SD 625, or the SdiStdSet is set to Auto and SdiStdFdbk is SD

525 or SD 625.

Table 3-6. Parameter Availability Based on Operating Mode

Condition

Enabled

Parameters

Disabled

Parameters

HD Operating Mode:

• 1035i/30

• 1035i/29.97

• 1080i/25 (295M)

• 1080i/30

• 1080i/29.97

• 1080i/25

• 1080p/30

• 1080p/29.97

• 1080p/25

• 1080p/24

• 1080p/23.98

• 720p/60

• 720p/59.94

• 720p/50

• YCrcErrCnt

• YCrcErrClr

• CCrcErrCnt

• CCrcErrClr

•EdhPrsnt

•EdhErrCnt

•EdhErrClr

SDI Operating Mode:

• SD 525

• SD 625
