68 HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual
Chapter 4: Specifications
DARS Input (HMX6801+B2/C2 Only)
Table 4-4. DARS Input Specifications
Item Specification
Type
• HMX6801+B2 Unbalanced,
AC coupled and balanced, transformer
coupled (user selectable)
• HMX6801+C2: Unbalanced,
AC coupled
Connector
• HMX6801+B2: BNC (IEC169-8) or
3-pin WECO
• HMX6801+C2: BNC (IEC169-8)
Impedance 75Ω (unbalanced)/110Ω (balanced)
Return loss >25 dB, 0.1 to 6 MHz (applies to coax
input only)
