HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual 73
Appendix A
Audio Bit Manipulation
Overview
The tables in this appendix contain information on the manipulation of
bits that occur when using HMX6801+B2/C2 and HMX6801+B4/C4
modules.
The following items are documented:
• “Manipulating Channel Status Bits (C-Bit)” on page 74
• “Manipulating Validity and User Bits (V-Bit and U-Bit)” on
page 77
• “Identifying Audio Characteristics (Audio Sampling Frequency
and Word Length)” on page 78
Table A-1. Description of Short Forms in the Appendix
RX Key TX Key
N=Not recognized N=Not transmitted
Y=Recognized Y=Transmitted
S=Recognized and stored,
passed-through, or both
