HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual 33
Chapter 3: Operation
Cross-Functional Parameter Changes
When you configure certain parameters, you force a change in other
associated parameters. Table 3-5 describes those parameters affected by
other option selections. Note that the forced setting (center column)
takes effect before the identified parameter (right column) becomes
enabled/disabled.
Table 3-5. Cross-Functional Parameters
Condition Forced Setting Enabled/Disabled Parameters
Output Ch01 Format = Non-PCM
or
Output Ch01 Format = Auto and
Out Ch01 Format Fb = Non-PCM
• Output Ch01 Gain = 0 dB
• Output Ch01 Invert = No
• Output Ch01 Gain = Disabled
• Output Ch01 Invert = Disabled
Output Ch01 Format = PCM
or
Output Ch01 Format = Auto and
Out Ch01 Format Fb = PCM
• Output Ch01 Gain = Enabled
• Output Ch01 Invert = Enabled
Output Ch02 Format = Non-PCM
or
Output Ch02 Format = Auto and
Out Ch02 Format Fb = Non-PCM
• Output Ch02 Gain = 0 dB
• Output Ch02 Invert = No
• Output Ch02 Gain = Disabled
• Output Ch02 Invert = Disabled
Output Ch02 Format = PCM
or
Output Ch02 Format = Auto and
Out Ch02 Format Fb = PCM
• Output Ch02 Gain = Enabled
• Output Ch02 Invert = Enabled
Output Ch03 Format = Non-PCM
or
Output Ch03 Format = Auto and
Out Ch03 Format Fb = Non-PCM
• Output Ch03 Gain = 0 dB
• Output Ch03 Invert = No
• Output Ch03 Gain = Disabled
• Output Ch03 Invert = Disabled
Output Ch03 Format = PCM
or
Output Ch03 Format = Auto and
Out Ch03 Format Fb = PCM
• Output Ch03 Gain = Enabled
• Output Ch03 Invert = Enabled
Output Ch04 Format = Non-PCM
or
Output Ch04 Format = Auto and
Out Ch04 Format Fb = Non-PCM
• Output Ch04 Gain = 0 dB
• Output Ch04 Invert = No
• Output Ch04 Gain = Disabled
• Output Ch04 Invert = Disabled
