52 HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual
Chapter 3: Operation
0, D Input Ch3A
Delay
Adjusts delay for input channel
AES 3A
0.0 to 1320.0 msec
0, E Input Ch3B Delay Adjusts delay for input channel
AES 3B
0.0 to 1320.0 msec
0, F Factory Recall Recalls the factory settings
• Off
•On
1, 1 Input Ch4A
Delay
Adjusts delay for input channel
AES 4A
0.0 to 1320.0 msec
1, 2 Input Ch4B Delay Adjusts delay for input channel
AES 4B
0.0 to 1320.0 msec
1, 3 V-Bit Mute
Enable
Enables audio channel muting upon
detection of an incoming set V-bit
• No
•Yes
1, 4 Out 01 Source
Select
Selects the source for output
channel 01
• AES 1A
• AES 1B
• AES 2A
• AES 2B
• AES 3A
• AES 3B
• AES 4A
• AES 4B
•AES 1 Sum
•AES 2 Sum
•AES 3 Sum
•AES 4 Sum
• TstTone 1
• TstTone 2
• TstTone 3
•TstTone 4
Table 3-11. Parameter Options - HMX6801+B4/C4 (Continued)
Bank, Rotary
Switch
Parameter
Name
Function Options
