HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual 59
Chapter 3: Operation
[RO] Group 3 Exists Reports the presence of audio group 3 in
the SDI stream
•No
•Yes
[RO] Group 4 Exists Reports the presence of audio group 4 in
the SDI stream
•No
•Yes
[RO] Grp. 1 Append Error Reports if an append error has occurred
in the group 1 embedder
•No
•Yes
[RO] Grp. 1 OverWrt Error Reports if an overwrite error has
occurred in the group 1 embedder
•No
•Yes
[RO] Grp. 2 Append Error Reports if an append error has occurred
in the group 2 embedder
•No
•Yes
[RO] Grp. 2 OverWrt Error Reports if an overwrite error has
occurred in the group 2 embedder
•No
•Yes
[RO] AES 1 Input Present Reports the presence of the AES 1 input
signal
•No
•Yes
[RO] AES 2 Input Present Reports the presence of the AES 2 input
signal
•No
•Yes
[RO] AES 3 Input Present Reports the presence of the AES 3 input
signal
•No
•Yes
[RO] AES 4 Input Present Reports the presence of the AES 4 input
signal
•No
•Yes
[RO] Input Ch1A Vbit Fb Reports the validity bit status of input
channel 1A
•Off
•On
[RO] Input Ch1B Vbit Fb Reports the validity bit status of input
channel 1B
•Off
•On
[RO] Input Ch2A Vbit Fb Reports the validity bit status of input
channel 2A
•Off
•On
[RO] Input Ch2B Vbit Fb Reports the validity bit status of input
channel 2B
•Off
•On
[RO] Input Ch3A Vbit Fb Reports the validity bit status of input
channel 3A
•Off
•On
Table 3-12. HMX6801+B2/C2 Read-Only Parameters—Remote Control Only (Continued)
Bank,
Rotary
Switch
Parameter Name Function Options
