62 HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual
Chapter 3: Operation
1080I Indicates a 1080I video source
is present
1080I video present
1035I Indicates a 1035I video source
is present
1035I video present
1080P/sF Indicates a 1080P/sF video
source is present
1080P/sF video present
525 Indicates a 525 video source is
present
525 video present
625 Indicates a 625 video source is
present
625 video present
Reference Present N/A N/A
Freeze N/A N/A
DARS Present
(HMX6801+B2/
C2 options only)
Indicates if the DARS signal
is present
DARS is present
AUDIO1 Reports the presence of AES
input 1
AES input 1 is present
AUDIO2 Reports the presence of AES
input 2
AES input 2 is present
AUDIO3
(HMX6801+B4/
C4 options only)
Reports the presence of AES
input 3
AES input 3 is present
AUDIO4
(HMX6801+B4/
C4 options only)
Reports the presence of AES
input 4
AES input 4 is present
Status Indicates nominal operating
status of the HMX6801+
module
Module is fully
configured and
operational
Table 3-13. Monitoring LEDs (Continued)
LED Function
Color Indication
when Lit (Green)
