76 HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual
Appendix A: Audio Bit Manipulation
4 3 to 6 [0000] Not indicated
[1000] 24 kHz
[0100] 96 kHz
[1100] 192 kHz
[1001] 22.05 kHz
[0101] 88.2 kHz
[1101] 176.4 Hz
[1111] User defined
NY
• RX ignores bits
• TX sets bits to [0000]
4 7 [0] Sample frequency not scaled
[1] Sample frequency scaled by 1/1.001
NY
• RX ignores bits
• TX sets bits to [0]
5 0 to 7 Reserved N Y
• RX ignores bits
• TX sets bits to
[00000000]
6 to 9 0 to 7 Alphanumeric channel origin data S Y
• RX ignores bits
• TX passed bits
unmodified
10 to 13 0 to 7 Alphanumeric channel destination data S Y
• RX ignores bits
• TX passed bits
unmodified
14 to 17 0 to 7 Local sample address code S Y
• RX ignores bits
• TX passed bits
unmodified
18 to 21 0 to 7 Time-of-day sample address code S Y
• RX ignores bits
• TX passed bits
unmodified
22 0 to 3 Reserved N Y
• RX ignores bits
• TX passed bits
unmodified
22 4 Bytes 0 to 5 reliability flag N Y
• RX ignores bits
• TX passed bits
unmodified
Table A-2. Channel Status (C-Bits) Data Description (Continued)
Byte Bit Function RX TX Remarks
