Settings Configuration
Purpose: The communication settings in the controller must be aligned with the details of the BMS at
the site.
To configure the communication settings, follow procedure below.
1. Access the Service menu
2. Press the or buttons to highlight Communication
3. Press the button
4. If the top of the screen does not say Communication, press the or buttons until it does
5. Press the button to move the blinking cursor and select the appropriate communication
option.
a. BACnetIP Ethernet
b. ModbusIP Ethernet
c. BACnet RS-485
d. Modbus RS-485
6. Press the button to return the blinking cursor to the top left corner
7. Press the or buttons to access the associated settings based on the selected option
8. Press the button to move the blinking cursor around the screen. Press the or
buttons to adjust settings. There may be multiple pages of settings including the IP address if
applicable.
a. To access the IP address settings, press the and buttons simultaneously for
several seconds, the screen will change
b. First release the button and second release the button
c. Arrow down to SETTINGS, press the button
d. Arrow down to TCP/IPv4 SETTINGS, press the button
e. Press the button to move the blinking cursor around the screen. Press the or
buttons to adjust settings.
