Operation and use 1B30E, 1B50E / 02 - Rev. 01
42
HATZ
Manual
6 Charge control
7 Operating indicator
8 Protective cap (only for standard instrument box)
Ignition lock
0 Off
I Operation
II Start
NOTICE
For further details on the instrument box, see chapter 5.2 HATZ
instrument box, page 30.
Procedure
NOTICE
▪ Start for max. 30seconds. If the engine is still not running
after that, turn the starting key back to position "0" and elimi-
nate the cause (see chapter 9.1 Troubleshooting, page
77).
▪ Turn the starting key to position "0" every time you want to
start the engine.
▪ The anti repeat device in the ignition lock makes it impossi-
ble for the starter to engage while the engine is running and
become damaged.
Step Activity
1 Remove the protective cap(8) from the ignition lock (only for
standard instrument box).
2 Insert the starting key all the way and turn to position "I". The oil
pressure indicator(5) and charge control(6) light up.
When the pre-glow indicator(2) lights up, wait until it goes out
and then continue with the next step.
3 Turn the starting key to position "II".
