1B30E, 1B50E / 02 - Rev. 01 Maintenance
HATZ
61Manual
CAUTION
Danger of injury
Prolonged contact with engine oil can lead to irritation of the
skin.
▪ Wear safety gloves.
▪ If there is contact with the skin, thoroughly wash the af-
fected areas of the skin with soap and water.
CAUTION
Danger of injury.
When working with compressed air, foreign bodies may fly into
your eyes.
▪ Wear safety goggles.
▪ Never direct the compressed air jet toward people or toward
yourself.
NOTICE
i
▪ Collect the emerging oil and dispose of it according to local
environmental regulations.
NOTICE
i
▪ The oil filter should be cleaned when the engine oil is
changed (see chapter 8.2.4 Change the engine oil, page
57), since oil will run out when the filter is pulled out.
Procedure
Step Activity Figure
1 Loosen the screw(1) by ap-
prox. five turns.
