Type AE101, AE301, AE501
Terminal Function Color ( HBM - cable)
1 Measuring signal WH (white)
2 Bridge excitation voltage BK (black)
2’ Sensor line GY (grey)
3 Bridge excitation voltage BU (blue)
3’ Sensor line GN (green)
4 Measuring signal RD (red)
5 Screen/Ground YE (yellow)
8 Synchronization (not with AE101)
9 Operating-voltage zero
*)
10 Output voltage
11 Supply voltage zero
*)
12 Supply voltage
Tab. 3.1: Amplifier connection
*)
Operating-voltage zero and supply-voltage are internally connected.
Terminal 5 of the Clip amplifier and the transducer’s screen connection should
be grounded (e. g. connected to the screen rail). If the transducers are
installed in a metallic housing with PG glands (e. g. control cabinet or ClipIG),
a large area of the transducer screen must be in contact with the PG gland.
