Technical data continued
Peak-value store unit
Output Peak value (alternatively, pos./neg. peak,
peak/peak 0.5 x peak/peak or current
value or envelope-curve value, tared and
amplified (1, 2, 5, 10-fold))
Peak-value store update-rate ms <1.3
Accuracy %
%
0.25 (in 6 ms)
0.05 (in 20 ms)
Transmission bandwidth Hz 15 (-1 dB)
Transient time for the output voltage ms 40 (to 99.9 %)
Discharge rate for envelope curve mV/s 5 ... 1000, adjustable
Control inputs Run/Hold;
(clear/peak)
Delay time for the control signals ms <8
Connection 12 series terminals for
wire ∅ 0.13 ... 1.5 mm
2
; 10 mm end
sleeves for strands
Operating voltage V
b
V DC 15...30, unstabilized
Power consumption mA <90
Nominal temperature range °C -20 to +60
Service temperature range °C -20 to +60
Storage temperature range °C -25 to +70
Weight g ca. 200
Protection to EN60529 IP20
Mounting On mounting rails to EN 50022
10 Accessories
To be ordered separately:
• Brackets 3-6450.0001
