40
Clip
HBM A0114-6.3 en
Refer to Tab. 5.4 for the discharge rate and the appropriate potentiometer
position. For more precise acquisition of the change in discharge rate use an
oscilloscope.
Switch S100/7 P1 Envelope-curve function
ON At right-hand stop Off
ON
Turn anticlockwise
from right-hand stop
Discharge rate 0.005...1 V/s
1 V/s
0 V/s
0.005 V/s
0.5 V/s
OFF No effect Off
Tab. 5.4: Envelope-curve adjustment
• Low-pass filter
It is possible to filter the peak-value store’s input signal. Refer to Tab. 5.2,
page 37 for the required setups. Please remember that the filter frequencies
cannot be adjusted independently of each other because they bear a constant
relationship.
5.5 Zero-point balance
A zero-point balance has been made at the factory. Should the output signals
for tare unit and store unit vary from zero, it is possible to correct them. Use
switches S100/1... 4 and S101/1 to define the output to be corrected.
S101/1 S100/1 S100/2 S100/3 S100/4 Function
ON ON OFF ON ON Tare output (terminal 5)
ON OFF ON ON ON Peak-value output (terminal 4)
Procedure
− Push and hold key S6.
− Use potentiometer Pl to adjust the zero point.
Should the balancing range available not be sufficient:
− Release key S6.
− Turn potentiometer to initial position.
− Restart the balancing procedure.
