39
Clip
HBMA0114-6.3 en
• Select peak value and amplification
Use the switches S100/1... 4 and S101/1 to define the type of peak value to
be stored (min/max, peak-peak) and the amplification.
S101/1 S100/1 S100/2 S100/3 S100/4 Function
ON OFF OFF OFF OFF Peak value minimum
ON ON OFF OFF OFF Peak value maximum
*)
ON OFF ON OFF OFF Peak-to-peak
ON ON ON OFF OFF (Peak-to-peak) x 0.5
ON OFF OFF ON OFF Tared minimum value (v=1)
ON ON OFF ON OFF Tared maximum value (v=1)
ON OFF ON ON OFF Tared minimum value (v=2)
ON ON ON ON OFF Tared maximum value (v=2)
ON OFF OFF OFF ON Tared minimum value (v=5)
ON ON OFF OFF ON Tared maximum value (v=5)
ON OFF ON OFF ON Tared minimum value (v=10)
ON ON ON OFF ON Tared maximum value (v=10)
OFF OFF OFF ON ON Minimum value (peak-value output)
and maximum value (tare output)
Tab. 5.3: Adjust peak value and amplification
*)
Factory setup
NOTE
With the minimum and maximum value setup selected, no taring is pos-
sible due to the fact that the tare output is used for output of the maxi-
mum value. Please make sure that for the maximum value (tare output)
amplification v=1 has been adjusted (switches S101/2...5, see page 37).
• Adjust envelope curve
Use switch S100/7 and potentiometer P1 to adjust the envelope curve operat-
ing-mode.
Procedure:
− First make sure that the ”Peak value” operating mode has been adjusted
(see page 38).
− Make sure that the type of peak value to be stored has been adjusted (see
Tab. 5.3).
− Set switch S100/7 to ”ON” position.
− Push and hold switch S6 and turn potentiometer P1.
