50
Clip
HBM A0114-6.3 en
TS101 tare and store unit
Accuracy class 0.1
Input voltage V "10
Input impedance kΩ 100
Output voltage V "10
Permissible load resistance kΩ ≥5
Linearity deviation % < 0.04 of full scale
Effect of a 10 K-change of the ambient
temperature
% < 0.1 of full scale
Effect of a 15 ... 26 V-change of the op-
erating voltage
% < 0.01 of full scale
Long-term drift over 48 h (after 1 hour
warm-up time)
% < 0.02 of full scale
Noise voltage of the output mV
pp
< 20
Control inputs (floating)
High signal level
Low signal level
V
V
11...30 (24 V nominal)
0 ... 5
Control output
High signal level
Low signal level
V
V
V
b
-2
<1
Output current mA <500
Tare unit
Output ms Net value (alternatively pos. peak val.)
Net-value amplification 1, 2, 5, 10-fold, selectable in steps, for tar-
ing of major initial loads
Tare error (with v=1) mV <4
transient time for the output voltage
after taring
ms 40 (to 99.9 %)
Low-pass filter (before taring) Hz 0.1 ... 12.5; adjustable
Transmission bandwidth kHz >10
Storage time for tare value Unlimited as long as V
b
is present (alterna-
tively, storage in EEPROM)
Control input Taring with rising edge
Delay time for taring ms <1
Control output Valid taring
