Clip
HBMA0114-6.3 en
EM201 Output stage module (with one module EM002)
EM201K2 Output stage module (with two modules EM002)
Accuracy class 0.1
Input
Voltage
Impedance
V
kΩ
" 10 (0 ... + 10 V)
> 11.5
Operating voltage V DC +15 ... 30
Power consumption
(fully assembled with 2 x EM002)
mA < 180
Nominal temperature range
°
C - 20 ... + 60
Service temperature range
°
C - 20 ... + 60
Storage temperature range °C - 25 ... + 75
Weight g 200
EM002
Output signal. selectable mA " 20 4 ... 20
Output current
with V
E
=10 V
with V
E
= 0 V
mA
mA
20 " 0.02
< " 0.04
20 " 0.5
4 " 0.2
Output current limit - - > 3 (switchable)
Permissible load resistance Ω < 500
Linearity deviation % full scale < 0.05
Internal resistance kΩ > 100
Measuring frequency range kHz 3 (-1 dB)
Degree of protection IP20
NT 101A, NT 102A
*)
power supply
Type NT101A NT102A
Input voltage V 230 "10 % 115 " 10 %
Permissible frequency range Hz 47 ... 63
Output voltage V
DC
15.3" 2 %
Output current at >25° ... +60° A
DC
0.4
Output power W 6.75
Efficiency approx. % 60
Current limiter (protected against sustained
short circuit) at
1.2 x
I
n
(permanently adjusted)
Residual ripple mV
pp
< 10
Maximum permissible cable length between
NT101A or NT102A and Clip module
m 3
Ambient temperature
°
C - 20 ... + 60
Excess-temperature protection
°
C typ.105 (trafo temperature)
Test voltage kV
eff
3.75 (prim/sec and prim/housing)
Degree of protection IP20
Weight g 420
*)
Version to DIN -VDE0551, EN60742 Protection class 1.
The maximum permissible continuous current is 450 mA.
