HBM AE501 - Page 12

13
Clip
HBMA0114-6.3 en
Type GR201 EM201, EM201K2 TS101
Terminal Function
1 Relay 1; Break contact Input 1; Ground*) Input; Ground
2 Relay 1; Make contact Input 1; "10 V Input ; "10 V
3 Relay 1; Center Output 1; Ground*) Output; Ground
4 Input 1; Ground Output 1;
"20 mA / 4 ... 20 mA
Output;
PVCS "10 V
5 Input 1; "10 V Input 2; Ground
*)
(only with
EM201K2)
Output;
TAR "10 V
6 Relay 2; Break contact Input 2; "10 V
(only with EM201K2)
Output;
TAR (24 V DC)
7 Relay 2; Make contact Output 2; Ground
*)
(only with
EM201K2)
Control; Ground
8 Relay 2; Center Output 2;
"20 mA /
4 ... 20 mA
(only with EM201K2)
Control;
Run/Hold
(24 V DC)
9 Input 2; Ground Ground
*)
Control;
Peak/Clear
(24 V DC)
10 Input 2; "10 V Ground
*)
Control;
TAR (24 V DC)
11 Supply zero Supply zero
*)
Supply zero
12 Supply voltage Supply voltage Supply voltage
Tab. 3.2: Connection of additional units
*)
Ground and supply zero are internally connected. GR201 has differential inputs.
