Electrical connection
26 A4243-1.0 HBM: public PAD4002A
Cable length in m Variation T
CS
in ppm/10K
1)
0.5 approx. 7
1 approx. 13
1.5 approx. 20
3 approx. 40
6 approx. 80
1)
Wire cross-section 0.14mm
2
, two wires connected in parallel in each
case.
The variation in sensitivity with temperature increases in
a cable with only 4 wires, as then double the resistance
is present for each line.
