Electrical connection
20 A4243-1.0 HBM: public PAD4002A
6 Electrical connection
Notice
Electronic components are sensitive to electrostatic dis
charge (ESD). So you must discharge your own static
electricity before touching the connector plugs.
6.1 Cable laying
Position the connection cable so that any condensation
or moisture that may occur at the cable can drip off
(loop). It must not be able to reach the electronics. Also
make sure that it is not possible for humidity or moisture
to get into the cables through open ends, thus preventing
damage to the cable sheath.
6.2 Pin assignment
Notice
The electronics must be operated with a supply voltage
of between 12 and 30V. Incorrect connections between
the supply and interface cables or the digital inputs/out
puts can cause irreversible damage.
So you must check the correct assignment of the con
nections before switching on for the first time.
The electronics have an 8‐pin connector plug (M12) for
connecting to one or more transducers (Fig. 6.1).
