Baud rate and bus cable lengths
The table below gives the maximum cable lengths for
CANopen, subject to the baud rate:
Baud rate in kBits/s 10 20 50 125 250 500 800 1000
Max. cable length in m 5000 2500 1000 500 250 100 50 25
The max. cable length is the total line length, calculated
from the length of all the stub lines per node (bus nodes)
and the line length between the nodes. The length of the
stub lines per node is limited, and depends on the baud
rate being used (see CAN bus documentation). In the
electronics, you can set the internal interconnection stub
lines to zero. If you are only using one connection pair
(only CANIN or only CANOUT), the cable length corres
ponds to the stub line length.
Explanations of CANopen communication can also be
found in the Online Help.
8 Operation via software
When required, download the PanelX software for para
meterization and visualization from the HBM website:
http://www.hbm.com/software ("FIT digital load cells &
AED weighing electronics" area).
