Anschließen von QuantumX‐Modulen
30 A3169-8.0 HBM: public CX22B / CX22B-W
DC 10V ... 30V
MX
X101
X102
MX
CX
Ethernet
WLAN
DC 10V ... 30V
Abb. 5.2 Anschluss von QuantumX‐Modulen an den
Datenrekorder via Ethernet
