Saving data on the Data Recorder
CX22B / CX22B-W A3169-8.0 HBM: public 69
Important
In the factory settings, the measurement data on the
removable CFast medium is written to Drive\Data and
enabled in the network as "External CFast data". Some
catman
[
EASY default directories are also set to this
directory.
So also create the directory on the new CFast. Enabling
is not necessary for working with catman
[
EASY .
10.3 Memory performance
Maximum cumulative recording rate
(data storage)
Internal memory SSD
With (temporary) dynamic measurement
data memory (BIN)
1)
With (temporary) static measurement data
memory (BIN)
2)
In FastStream mode2
2)
MS/s
MS/s
MS/s
4
> 5
> 5
For the installed CFast
With (temporary) dynamic measurement
data memory (BIN)
1)
With (temporary) static measurement data
memory (BIN)
2)
In FastStream mode
2)
MS/s
MS/s
MS/s
3
> 5
> 5
1)
Test conditions: 14 modules (FireWire), 56 DAQ channels, 8 bytes per measured value, 2 data
rate groups, no visualization objects
2)
Test conditions: 14 modules (FireWire), 56 DAQ channels, 8 bytes per measured value, 1data
rate group, no visualization objects
