Saving data on the Data Recorder
66 A3169-8.0 HBM: public CX22B / CX22B-W
10 Saving data on the Data Recorder
10.1 Memory partitioning
The available memory in the CX22B‒W Data Recorder
allocated as follows:
S 16 GByte are used for the operating system and are
specifically protected against (unintentional) change
(partition C, EWF filter).
S 48 GByte are readily available for the application and,
optionally, for measured data (partition D).
C:\ Windows 8
Embedded
including
catman
EASY
D:\ Application and
measurered data
E:\ Measurement
data
Removable CFast card (in
scope of supply 8 Gbyte)
16 GB
48 GB
Internal SSD Internal SSD
Fig. 10.1 Partitioning of the available memory
Important
All changes made in partition C: are only temporary, as
this partition is protected against change (EWF,
see Section 10.4). In the start screen, click on Commit
changes and reboot, to permanently save the new set
tings or the newly installed software. The CX22B‒W is
then rebooted, so you must set up the connection again
after the restart.
