Operating the Data Recorder
30 A3169-8.0 HBM: public CX22B / CX22B-W
6 Operating the Data Recorder
6.1 Operation with monitor and
keyboard/mouse
This type of operation is the simplest. It does not require
any configuration, but you will need a monitor with digital
input (DVI) and a mouse and keyboard with USB connec
tion.
Connect the mouse and keyboard to the USB sockets of
the CX22B‒W. The monitor is connected to the DVI
socket with a commercially available DVI monitor cable
(see Fig. 4.1 on Page 15 for all connections). Connection
via VGA is not possible, not even with a DVI/VGA
adapter plug, as the leads required for VGA are not as
signed.
Switch on the power supply and wait until the boot
process is complete and the module is ready.
Important
The CX22B‒W factory setting for input language (key
board layout) is EN (English). If you connect a keyboard
with a different layout, you should select Exit to Win
dows in the start screen and then press Shift and Alt, or
change the input language via the language bar in the
task bar.
If necessary, use the Windows control panel ("Regional
and Language Options") to set the Location) to your
country. The setting influences the digit settings and the
time, for example.
Make other settings via the Data Recorder start screen.
