Connecting QuantumX modules
CX22B / CX22B-W A3169-8.0 HBM: public 29
DC 10V ... 30V
MX
X101
X102
MX
CX
Ethernet
WLAN
DC 10V ... 30V
Fig. 5.2 Connecting QuantumX modules to the Data
Recorder via Ethernet
