Operating the Data Recorder
CX22B / CX22B-W A3169-8.0 HBM: public 39
6.2.2 Connection via a network
The settings for the CX22B‒W Data Recorder again de
pend on your network configuration. Please contact your
network administrator to obtain the correct settings.
► Install the "HBM Device Manager" program from the
system CD.
► Launch the program on your desktop or via the Win
dows Start menu −> All programs −> HBM −> HBM
Device Manager
► Click on Find modules.
► All the QuantumX and Somat modules, including the
Data Recorder, will appear in the list.
► The IP addresses and subnet masks of the PC inter
faces are displayed in the Settings of my computer
section on the left.
► In the TCP/IP settings for CX22B‒W section, click
on LAN and select DHCP off - normal in networks.
Please note the specifications of your network admin
istrator.
► Click on Apply and wait until the new setting is shown
at the top. The symbol should change to the
symbol and thereby indicate that a connection is
possible.
► Select the CX22B‒W once again in the list at the top
and then click on Remote connect.
For the next steps, please proceed as in the previous
Section.
