Connections and displays
20 A3169-8.0 HBM: public CX22B / CX22B-W
4.5 Connector strip for backplane
integration
The recorder can be integrated into the BPX001/002
backplane.
4.6 USB 2.0 and USB 3.0 interfaces
Devices such as a keyboard, mouse, monitor, printer, as
well as GPS sensors or data memory such as a USB
flash drive, can be connected.
Tips for use are available for the connection of GPS sen
sors via RS232 or USB.
Notice
If you have to install device drivers, please note Section
12.4.
4.7 RS232 interface
An NMEA‐based GPS sensor can be connected via
RS232, for instance. The interface does not provide a
voltage supply. Other serial buses can be integrated to
the software on demand. A wide range of solutions is
already available.
