Connections and displays
CX22B / CX22B-W A3169-8.0 HBM: public 15
4 Connections and displays
USB 3.0
START/STOP
button
RS‐232‐C
Digital I/Os
Status LEDs
Monitor (DVI-D)
WLAN antenna
Ethernet
USB
Fig. 4.1 CX22B‒W connections on the front
